Product Overview

The E-link 24-Port Industrial DIN-Rail Fiber Patch Panel provides rugged, high-density fiber management for direct termination and fusion splicing in space-constrained environments. Constructed with premium anodized aluminum (RAL 7035), this panel delivers durable, lightweight performance while maintaining a compact footprint for seamless integration with other DIN-rail mounted equipment in enclosures or cabinets.

Key Features & Benefits

✅ High-Capacity Fiber Management

• 12 ST duplex adapters (24 ports total) for high-density patching

• Supports both direct termination and fusion splicing

• Tool-less access for quick maintenance

✅ Industrial-Grade Durability

• Anodized aluminum housing (corrosion-resistant, natural finish)

• DIN-rail mountable (TS-35 standard) for easy industrial cabinet integration

• IP20 protection against dust and light moisture

✅ Space-Saving Design

• Ultra-compact for high-density enclosures

• 1U equivalent height for rack compatibility

• Optimized for crowded control panels

✅ Wide-Range Applications
✔ Industrial automation (IEC 61850-3 compliant)
✔ Telecom/FTTH distribution
✔ 5G fronthaul/backhaul terminations
✔ Data center cross-connects

Technical Specifications

1. High-Density Fiber Termination

• 12 ST duplex adapters (24 ports total) for high-capacity fiber patching

• Supports both direct termination and fusion splicing

• Tool-less adapter access for easy maintenance

2. Industrial-Grade Construction

• Anodized aluminum housing (RAL 7035 grey)

• IP20 protection against dust and light moisture

• DIN-rail mountable (TS-35 standard) for easy integration

3. Optimized Cable Management

• 2x PG 11 cable glands for secure fiber entry/exit

• Strain relief design to prevent cable damage

• Compact footprint (1U equivalent height)

4. Rugged Environmental Performance

• Wide temperature range: -40°C to +80°C (-40°F to 176°F)

• Vibration resistant for industrial environments

• Corrosion-resistant aluminum construction

5. Customization Options

• Alternative adapter configurations available (FC/SC/LC)

• Custom labeling for easy identification

• Optional splice tray integration

Key Technical Specifications:

• Adapter Type: ST duplex (12 adapters, 24 ports)

• Mounting: DIN-rail TS-35

• Material: Anodized aluminum

• Color: RAL 7035 grey

• Cable Entry: 2x PG 11 glands

Professional Application Scenarios

1. Industrial Network Infrastructure

• Factory automation control systems (IEC 61850-3 compliant installations)

• Process industry networks for oil/gas refineries and chemical plants

• Railway signaling communications (EN 50155 certified environments)

• Power utility substations requiring rugged fiber management

2. Telecommunications Deployments

• FTTH (Fiber-to-the-Home) distribution frames in MDUs

• 5G fronthaul/backhaul termination points for small cell networks

• Central office fiber distribution systems

• OSP (Outside Plant) fiber management for last-mile connectivity

3. Data Center & Enterprise Networks

• High-density fiber cross-connects in space-constrained racks

• Campus network backbone terminations

• Secure government/military networks requiring organized fiber routing

• Financial data centers with strict cable management requirements

4. Critical Infrastructure Applications

• Intelligent transportation systems fiber nodes

• Public safety communication networks

• Utility monitoring systems (water/gas/electric)

• Smart city optical distribution networks

Technical Advantages:
✔ Carrier-grade reliability with anodized aluminum construction
✔ High-density termination: 12 ST duplex adapters (24 ports)
✔ Industrial durability: IP20 protection, -40°C to +80°C operation
✔ Space-efficient design: Compact DIN-rail mounting (TS-35 standard)

Technical Indexes

Ordering Informatio
